$25.00 USD
A high quality, dual 2.4A (24W, 4.8A total) USB car charger to power your GoPro and/or CamDo product (Blink, Bullet or Dash). It includes smart charging technology to deliver the fastest charge possible, while avoiding overloading, overcharging and overheating.
Compatible with other smart devices including all leading brands of smartphones and tablets.
CamDo recommends only using USB power supplies with a minimum rating of 2.0A with your GoPro.
Perfect for use with our GoPro Dashcam pack - see here for further details.
$35.00 USD
Product Code: USB-Meter
The USB Power Meter can be used to check the actual power consumption of the camera (phone, iPad, or any other USB powered device). It inserts between the battery or charger and the device and displays the voltage and current in real time.
This allows you to understand the actual power consumption of the camera in various modes and test the charging rates in various configurations.
Measures voltages from 3.0 to 7.0 volts (±0.1V). Current from 0 to 2.5A (±0.01A).
LED Display
Accurate Measurement
$83.00 USD
Product Codes: VB-004N (Naked)
VB-004A (Acrylic + Cable)
VB-004C (Naked + Cable)
The GoPro Video Monitor Adapter plugs into the connector at the back of all GoPro HD HERO, HERO2, HERO3, HERO3+, and HERO4 cameras. The adapter provides 480i SD composite video compatible with all LCD and CRT monitors and video transmitters and receivers.
The CamDo video adapter for the GoPro camera converts the signal normally displayed on the GoPro LCD BacPac to a composite video signal which can be displayed on any monitor with a composite video input.
With a large display, separate from the camera, you can easily frame your image and navigate the GoPro menus to set up for a shoot.
 |
The Naked PCB version is fully assembled, programmed, and ready to use. Just connect your own video cable and plug the board into the camera. |
 |
The Naked PCB + Cable version includes a short coax cable with a male RCA plug compatible with most consumer video devices. |
 |
The Acrylic + Cable version is enclosed in a custom made acrylic enclosure which fits comfortably in the GoPro extended backpacs and includes the cable with RCA connector. |
Compatible with all video transmitters.
The composite video signal can also be transmitted by any video transmitter to a compatible receiver for wireless remote viewing. Tiny video transmitters for R/C planes and quadcopters can be used in real time with no delay for FPV flying or just framing the image being captured by the GoPro camera in high definition.
Video Signal Transmission
Remote Trigger (available with PCB version)
External Output (available with PCB version)
No Additional Battery Required
|
Camera |
Compatibility ( Y / N ) |
|
HERO5 |
✘ |
|
HERO5 Session |
✘ |
|
HERO4 Black |
✔ |
|
HERO4 Silver |
✔ |
|
HERO4 Session |
✘ |
|
HERO (2014) |
✘ |
|
HERO3+ Black |
✔ |
|
HERO3+ Silver |
✔ |
|
HERO3 Black |
✔ |
|
HERO3 Silver |
✔* |
|
HERO3 White |
✔ |
|
HERO2 |
✔ |
|
HERO |
✔ |
Compatible with the GoPro camera with a HERO Port connector on the back of the camera.
* Trigger function not available on the HERO3 Silver.
Information about how to use the PCB Video Monitor Adapter’s trigger and LED pins can be found here.
View Application Notes for Advanced Users >
Frequently Asked QuestionsWhich models of GoPro cameras are compatible with the Video Monitor Cable?
All models of GoPro cameras equipped with a HERO Port connector on the back are compatible with the Cam-Do Video Monitor Cable. The original HERO 980 is not compatible. All other cameras including the HERO3+ and HERO4 models are compatible.
Does the adapter fit in the waterproof back?
The adapter fits inside the extended BacPacs provided by GoPro with the LCD display, battery BacPac and WiFi BacPac. The cable fits through the slot in the BacPack.
Can the adapter be used underwater?
A waterproof version for underwater use with a cable leading to the surface is currently in development. We have tested it to 30 feet with a 100 foot cable and will be doing more testing before offering this new product. It will probably come with a cable, a video output plug, and optionally the possibility of powering the camera from a 12 volt source and triggering the start and stop with a remote button. If such a product is of interest, please contact us to participate in the final design decisions by telling us how it would be useful for you.
Can the camera be powered by the adapter?
Charging via the video board works with HD HERO and HERO2 cameras. The adapter has connections for 5 volt USB power to keep the camera battery charged for long usage or to power the camera without the battery when trying to minimize weight. External power via the Adapter does not work with the HERO3 or HERO4 camera. For HERO3/3+, Battery Eliminators should be used. For HERO4, the USB power input should be used.
I bought the bare board, where do I connect the video out?
VIDEO For video out, connect a cable to the contacts at the lower right. No other connections or power supply are required.
LED An LED can be connected for visual indication of when the camera is on, or for telemetry in FPV systems, or feedback in automated control systems.
Trigger Closing a contact across the trigger connections briefly will turn on the camera. One button mode can be used to start filming. Super One Button Mode scripts can be used with HERO3 and HERO3+ cameras. CSI scripts are used for HERO4 cameras.
5V DC can be applied to power the GoPro camera.
If your board is a previous revision click here to see the connection diagram.
Free
We're always trying to improve our products. Please click here to answer a few questions about our WIGO application.
WiGo is a Windows application designed to communicate with GoPro WiFi enabled cameras that can be used to change the camera settings, preview the image, and download photos and videos directly to your PC from the SD card.
Shortly after the iPhone application was released by GoPro, a number of enterprising individuals began to catalog the WiFi commands sent from that app to the GoPro Wifi BacPac. They were generous enough to share their observations on the GoPro User Forum. In particular, dough29 contributed enormously to the task of documenting the List of GoPro Wifi BacPac Commands and has built RemoteGo, an Android app to control the camera. This software builds on their work. Thank you.
WiGo does not require any installation. Download the WiGo.exe file (which will be delivered to you via email) to the folder you wish to use and run it. Your browser and Windows will warn you that this is unsafe. They are right. It is always risky to download an executable file from an unknown source. Never install WiGo or any other program if you are unsure of the source. If you download from cam-do.com, WiGo.exe is coming directly from the author. It does not contain malware of any kind. Never download WiGo.exe from any other site.
Disclaimer:
This is beta testing software. Use at your own risk. This software may damage your camera. The responsibility is entirely with the user. The author accepts no responsibility for any damage that may be caused by using this software.
Can WiGo be set up to automatically take pictures and upload them to a web site for remote viewing?
The free version does not include those features. We are working on a WiGo Professional version that will incorporate many of the extra features that have been requested by our corporate clients. The ability to control multiple cameras with one WiFi adapter and upload the captured photos to a web site on a regular schedule is the most important feature of WiGo Pro. If this is a feature you would like to make use of, please contact us for further details or to influence our design decisions.
What versions of Windows will WiGo run on?
It has been tested on Windows 10, Windows 8, Windows 7 and Windows XP. There is no reason it shouldn't run on almost all Windows versions released in this century. SSID display and automated camera selection are only available in Windows 7 and 8. Users report that it works with the Windows 8 Microsoft Surface Pro Tablet.
Will it work with my camera?
It works with all 3 versions of the HERO3 Cameras and the HERO2 with the WiFi BacPac accessory. There are some features that only work with particular cameras because of the features GoPro has included or the way they have configured their firmware.
HERO3+ includes some new settings and status feedback that were not available in the previous cameras. WiGo works with the HERO3+, but not all settings. HERO4 and HERO5 is not supported.What are the users saying about WiGo?
Feedback has been almost 100% positive. Quite a few users have been happy enough to donate. For example, read these unsolicited emails:
I'm just writing to thank you so so much for the WiGo... i`ve been for about a week or so trying to get the GoPro App through an android emulator for PC and was just about to lose my goddamn mind when I stumbled upon your website, and your wonderful wonderful software. Congratulations on developing this way before GoPro did, or should have done (still dont know why) but the program works amazingly. I don't know if you updated the software since the last time you posted any comments, but I have a HERO3 WHITE ED. and EVERYTHING worked perfectly !!!!! The Previews, the functions, the mode selection, the options selection....everything commanded through the software, the only issue that I believe is normal is the 2 or 3 second delay on the preview image !! but that is expected...and being what it is...even welcome...lol !!!!
- Leonardo in Sao Paulo
Your program fixed my HERO3 Silver blue light problem!!!
Ever since I did the newest firmware update on my HERO3 Silver the blue WiFi lights don't work anymore. This started to cause a problem because you would never really know when the WiFi antenna was on or off. The WiFi button is very easy to activate by accident. It would turn on with out me knowing, rendering the camera battery dead when you wanted to use it. When the camera is off the only way to know the WiFi antenna is on was the blue light blinking.
I found your program online wanting to connect my GoPro to my laptop via WiFi for streaming or just something neat to have.
First of all, on my HERO3 Silver everything works perfectly!!!
I was messing around with the settings for the LEDs in WiGo. Turned the LED setting off then on and now the blue lights work again!!!! Don't know how it fixed it, but it did and has worked ever since.
Now I know when the antenna is really on or off again.
Thank you thank you thank you for such an awesome program. Your time is much appreciated.
I will certainly mention this awesome program and website to my fellow users and also suggest a donation to your efforts.
Thanks again!
- Josh
Tips & Troubleshooting
Streaming video is delayed or cuts off after a few seconds.
The delay is normal and is part of the GoPro implementation.
Some users have reported the streaming working without problems. Others seem to have it stop intermittently. Make sure the firmware in the camera is up-to-date and installed properly. Sometimes a manual install fixes problems after GoPro's automated install has appeared to work. Make sure you are using the latest version of VLC. Restart your computer after updating VLC. WiGo does no more than pass the address of the camera's streaming feed to VLC.
One VLC setting that improves streaming is under VLC - Tools - Preferences - Input & Codecs - Default Caching Policy - select Lowest Latency. There are a lot of settings which can be optimized and perhaps a VLC guru can tell us the best combination.
I see the SD Card on the HERO3 Black but there are no image files.
The latest firmware from GoPro for the HERO3 Black disabled the image file display on the camera's web server. It is possible to run a SOBM script on your SD card which will modify the firmware in the camera to show the files.
Is it possible to capture the streaming video or forward it via the internet?
Yes, it is. It can be done using the features of VLC or with utilities such as FFmpeg and FFplay. TechAnswerGuy has blogged about the process and gmore70 has created a tutorial video showing how to stream GoPro video on YouTube and UStream.
How can I extend the range from my camera to my computer?
There are several ways to do this. One is to use a range extender, which repeats signals from the computer to the camera and vice versa.
Can I control multiple cameras with one computer?
There are several ways to do this. WiGo Pro can access multiple cameras and upload photos using FTP with a single WiFi adapter by accessing them sequentially or control multiple cameras connected to separate WiFi adapters by changing the camera IP address.
Known Bugs
The video mode settings are incomplete. Some video mode settings work on some cameras, but the complete set of mode values for all of the cameras has not been implemented at this time. Some mode settings may be incorrect on some camera models and work correctly on others.
Sold Out
Product Code: 6Watt - HSO01
9Watt - HSO03
Our Solar Enclosures use a 9Watt solar panel to recharge the included V15 battery.
Our outdoor enclosure is fitted with a sturdy aluminum mounting bracket that contains multiple ¼"-20 threaded holes on the top, back, and bottom for use with standard tripod screws. It also has 2 slots at the back for using straps to attach the enclosure to a pole. The solar panel is removable and attached to the top of the enclosure using a dual ball socket arm so it can be positioned for optimum sun exposure. The solar panel charges the included Lithium Polymer battery which outputs 5 volts to power the camera or other accessories in a weatherproof enclosure.
We also offer a sturdy swivel mount for easy mounting to a pole or flat surface, check out the product page here.
The enclosures are designed to be crushproof and dust tight. Inside the weather resistant enclosure contains an aluminum bracket designed to hold the GoPro camera, and CamDo Controller board. It is possible to access the SD card, or USB connector without removing the camera. If the camera needs to be replaced, the fit is extraordinarily tight, guaranteeing that the camera will be in the exact same position as before. The interior has space for extra batteries or other accessories. The enclosure is fitted with a standard 55mm filter adapter and a neutral density UV optical glass “digital filter” is included. You can replace the filter with your filter of choice.
Our case has several mounting options for different situations. There are two ¼” locking holes, one on each side of the case, through which a padlock, bolts, or threaded rods can be used to secure the contents of the box.
There are 2 slots on the back of the aluminum mounting bracket which allow it to be easily attached to a pole or structure using straps such as hose clamps or zip ties. The tripod screw holes at the back of the bracket can then be used to angle the camera.
We also offer a high quality swivel mount bracket that can be added to your system which allows fantastic aiming flexibility. Read more here.
The aluminum mounting bracket has multiple tripod screw holes on the top, back, and bottom that can be used with any standard photographic tripod or mounting bracket with a normal tripod thread (¼"-20). ¼"-20 bolts are easily obtained from any hardware store if you are making your own mount. There are hundreds of different compatible mounting brackets and magic arm brackets.
9Watt Solar Panel
Colors Available
* We are currently stocking only the favorite pick, black. All of the colors are available on custom orders, but please allow up to one month delivery time. We will add other colors to general stock if there is sufficient demand.
|
Camera |
Compatibility ( Y / N ) |
|
HERO5 |
✘ |
|
HERO5 Session |
✘ |
|
HERO4 Black |
✔ |
|
HERO4 Silver |
✔ |
|
HERO4 Session |
✘ |
|
HERO (2014) |
✘ |
|
HERO3+ Black |
✔ |
|
HERO3+ Silver |
✔ |
|
HERO3 Black |
✔ |
|
HERO3 Silver |
✔ |
|
HERO3 White |
✔ |
|
HERO2 |
✘ |
|
HERO |
✘ |
Compatible with the GoPro HERO3, HERO3+ and HERO4 cameras.
Which CamDo Solar System is right for my GoPro camera?
Our currently available Solar-9W products are compatible with Hero3, Hero3+ and Hero4 cameras. Refer Compatibility tab.
How do I setup my system?
View the Solar Power System set-up guide here.
How long does it take to charge the battery?
In direct sun, the V15 (4,000 mAH Lithium Polymer battery) will fully charge in approximately 5.5 hours using the 6W solar panel. Where the weather is frequently cloudy/raining we recommend the 9W solar panel option. The battery system incorporates protection against overcharging, over discharge, over current (short circuit), unusual voltage input, and temperature extremes.
Will the solar panel be able to keep my time lapse running indefinitely?
This would depend on the shooting cycle used and the sun exposure available in your location. We advise all customers to calculate their battery needs due to the many variables. We have a Time Lapse Calculator that can be used to help determine your ideal shooting interval and how long your battery should theoretically last using our controller boards and batteries. The Calculator also gives the rate at which the solar panel should be able to recharge your battery at your given location and with the panel angle that is used. Keep in mind that temperature, battery fatigue, and other electrical inefficiencies will prevent the camera from using the full battery capacity.
What is the original dust and water ingress rating of your enclosures? Can I submerge your Solar or DRY enclosures?
The enclosures have an IP67 rating prior to installation of CamDo accessories. Our Solar and DRY enclosures are not meant to be immersed in water.
How long will the battery last before it is discharged?
It depends on many factors including your latitude, the amount of sun and cloud during your shoot, the controller you are using, the camera you are using and the shooting schedule you have programmed. There are too many variables to give a perfect answer but we have created a Time Lapse Calculator to work out the best setup for your shoot in your location.
This uses our analysis of the power consumption of the various GoPro cameras and provides an explanation of how to calculate the theoretical battery life.
Practically, we have run the system indefinitely taking one picture every 15 minutes with the WiFi on, in Canada in the summer.
Why is "Always On" mode for batteries important?
Since our controllers turn the camera off between triggers to conserve power, Always On mode is important to prevent the battery from automatically turning off. Most of the USB battery packs on the market have an automatic power saving feature which turns off the battery if the battery is not constantly supplying power to a device. If the GoPro is powered off for more than a few minutes between triggers, the external battery might automatically shutdown due to inactivity. However, our V15 battery packs have two modes of operation, the standard Auto Off mode and an Always On mode. The Always On mode prevents the battery from automatically turning off when insufficient current is being drawn due to the camera being powered off.
Refer to our support page here to make sure you are in "Always On" mode when setting up your system. Refer Step 2 of the guide.
Make sure to disconnect the battery from all devices to check this. If you hold down the power button for six seconds and the charge indicator flashes 3 times and stays lit for a second or two, you are now in Always On mode. If you hold down the power button for six seconds and the charge indicator flashes 3 times and then goes dark straight away, you are in Auto Off mode.
How can I avoid condensation on the lens?
Our enclosures have an integrated auto-pressure valve that equalizes the atmospheric pressure difference to reduce condensation. The IP67 micro vent allows air to pass through while preventing water from entering. If you need additional protection against condensation, the extra space in the solar enclosure allows for one or more sacks of desiccant to be inserted in the box. For even more protection, there are some products available to coat the lens, such as those used on ski-goggles. The standard 55mm threaded lens filter can also be replaced with another 55mm threaded lens that already has anti-fog characteristics or coating.
TIP: Condensation is a result of humid air being sealed in the box when you close it and condensing when there is a temperature change. Try to close the box in as dry an environment as possible. If you need additional protection against condensation, the extra space in the solar enclosure allows for one or more sacks of desiccant to be inserted in the box. For more information, Google for avoiding condensation in underwater cameras, where the problem is discussed at length by many experienced photographers.
Can I lock the case?
There are two ¼” locking holes, one on each side of the case, through which padlocks, bolts, or threaded rods can be used to secure the contents of the box.
Is it possible to separate the solar panel from the box?
Yes. The solar panel is removable and has a 4ft charging cable that enters the enclosure through a waterproof cable gland at the bottom of the enclosure.
Can I mount the solar panel remotely from the enclosure?
Yes. However, if you need to place the panel remotely from the enclosure, attention must be paid to the gauge of wire used to connect the solar panel to the battery. The connectors on the solar panel cable are 3.5mm outer diameter, 1.1mm inner diameter barrel power connectors. So you'll need one end male (M3.5x1.1), the other one end female (F3.5x1.1). A local electronics store will have these connectors. We recommend using the largest cable that can physically fit into the particular connector you source to minimize voltage drop from the panel to the battery. The voltage drop must not exceed 0.5 volts. A 16 AWG or larger wire is recommended for distances exceeding a few feet.
Which cables and adapters come with the system and what do I use to connect the battery to the solar panel?
The system comes with all necessary cables along with a number of useful adapters for charging phones and other cameras as well as the cables used to charge the battery.
Refer Step 6 of our Solar Setup Guide.
Can I use this system to charge other devices as well?
Absolutely. The V15 battery pack can be used to charge any 5V device.
Can your systems be used for other purposes than GoPro cameras?
Yes. You can remove the GoPro mounting fixture to provide extra space for your equipment. The solar panel, battery, and enclosure can be used for your custom system or just used as a remote charging station for phones and other USB chargeable devices.
Does the enclosure O-Ring seal require special care?
The case is equipped with a hollow core EPDM gasket that has been designed to give superior performance and resist compressive deformation over time. To ensure a watertight seal, the gasket must be free of cuts, abrasions or tears. Debris or foreign material caught between the sealing rib on the bottom of the case and the gasket on the top of the case will prevent the case from sealing properly. A coat of an automotive type surface protector is recommended to help prevent dirt and debris from sticking to the seal. If the seal becomes damaged a replacement seal can be ordered from Cam-Do.com.
Special care should be taken to ensure that wires or cables do not get trapped in the door when it is closed. The power-claw latches can exert extreme force, resulting in damage to the cable and the O-ring seal.
General support can be found on our Support pages here.
The CamDo Blink controller board is typically used with our Solar Enclosures to provide programming flexibility while significantly reducing power consumption. Information on Blink can be found on the following pages:
Also, read the FAQ's tab for more information.
$28.00 USD
The OtterBox 2500 Series case is a high quality drybox to keep your valuables dry and protected when you're outdoors—great for paddling, hiking and camping.
It is a cleverly-made drybox designed to withstand submersions up to 100 feet! Waterproof, crushproof and airtight, these cases provide protection for your cell phone, sunglasses, PDA, keys, GoPro / small digital camera and more!
