$259.00 USD
Product Code: CBL01
Use Blink to achieve long term time lapse or motion detection for your next project. Just plug it into your GoPro and use the Blink app to connect and configure up to 10 separate time lapse schedules using a smartphone, tablet, computer, or any WiFi enabled device which has a web browser (no cell service or internet connection required). For more information, see the Quick Start Guide and User Manual. Also check out our tutorial videos for a quick overview of the user interface.
A WiFi network with internet access is only required if you would like to use our optional Blink Email status feature to provide daily status updates.
If you are looking at a long term time lapse you may be interested in our general time lapse and construction time lapse packs which incorporate an external solar system for long term deployment or where finding a power supply is difficult or expensive.
Compatible with the GoPro HERO3+ Black and HERO4 Black/Silver cameras. Note - Blink may work with HERO3+ Silver cameras but is not officially supported by CamDo due to the general unreliability of the HERO3+ Silver cameras as they get older. Please use our Time Lapse Intervalometer for older camera models.
Our HERO5 controllers are expected to be available by mid 2017. However, while the HERO5 has video image stabilization and higher quality microphones, the HERO4 cameras have the same 12MP image resolution and the HERO4 Black achieves the same video resolution at 4K 30fps.
|
Camera |
Compatibility ( Y / N ) |
|
HERO5 |
✘ |
|
HERO5 Session |
✘ |
|
HERO4 Black |
✔ |
|
HERO4 Silver |
✔ |
|
HERO4 Session |
✘ |
|
HERO (2014) |
✘ |
|
HERO3+ Black |
✔ |
|
HERO3+ Silver |
✘ |
|
HERO3 Black |
✘ |
|
HERO3 Silver |
✘ |
|
HERO3 White |
✘ |
|
HERO2 |
✘ |
|
HERO |
✘ |
Can I have a time lapse and motion detection simultaneously?
Yes, Blink allows for multiple schedules to be active at a time.
What happens if there is a conflict between schedules?
If multiple schedules have been set and there is a conflict between them, priority is given to the lower numbered schedule. For example, schedule 1 has priority over schedule 2.
Does Blink fit inside the standard GoPro housings?
Yes, if housing external batteries is not an issue, Blink can be used with the GoPro Frame Mount or the extended backdoors included in the GoPro Back Door Kit that are designed to clip into the standard housing to provide space to fit GoPro BacPac accessories.
What housings does CamDo offer that have space for Blink and external battery packs?
Blink is typically used with our Outdoor Enclosures to also house extra batteries and come with three power options, a 6Watt solar panel, 9Watt solar panel, or without a solar panel that is normally used for shorter deployments, when you can return regularly to recharge the batteries. The Outdoor Enclosures have space to fit up to two of our V44 (44watt-hour) battery packs.
If you require a waterproof solution, our aluminum Deep underwater housing allows for use of Blink and the GoPro to a depth of 2000ft, while the DeepEXT housing extension can fit up to three V15 (15watt-hour) battery packs.
How long will the battery last if I shoot some number of photos per hour?
Calculating battery life is non-trivial. It depends on the camera model, firmware version, SD card speed, lighting conditions, battery size, age of the battery, ambient temperature, and more. To help you understand the issues and to calculate estimated battery life, consult the Camera Power Consumption Study and our Time Lapse Calculator.
If I know approximately how long my project is, how do I determine the ideal interval between triggers?
The ideal shooting interval is normally determined by the length of the final time lapse video clip, capacity of the SD card or battery capacity available. Our Time Lapse Calculator can be used to help determine the ideal interval between photos as determined by these variables.
Why is "Always On" mode for batteries important?
Since Blink turns the camera off between triggers to conserve power, Always On mode is important to prevent the battery from automatically turning off due to periods of inactivity. Most of the USB battery packs on the market have an automatic power saving feature which turns off the battery if the battery is not constantly supplying power to a device. If the GoPro is turned off for more than a few minutes between triggers, the external battery might automatically shutdown due to inactivity. However, our V15 and V44 have two modes of operation, the standard Auto Off mode and an Always On mode. The Always On mode prevents the battery from automatically turning off when insufficient current is being drawn due to the camera being turned off by Blink to conserve power.
Does Blink retain the shooting schedule when power is removed or lost?
When all power is removed, Blink will retain the programmed shooting schedule. However, Blink does not have an internal battery to retain the time and date settings. When power is restored to Blink, it will determine the clock time and date information from the GoPro camera.
Can I switch the SD card in the middle of a time lapse schedule?
Yes, the SD card is "hot swappable". If an interval occurs when the SD card is out of the GoPro, Blink will continue the shooting schedule by triggering the camera to turn on and off, however, no image will be taken since there is no SD card to save the image to.
How do I change Blink's shooting schedule in the middle of a project?
Blink's WiFi can be turned on or off by using the supplied push button remote plugged into the board's 2.5mm input. Blink's WiFi only remains active for 15 minutes to program the new settings before the WiFi is automatically turned off to conserve power. If the camera is not easily accessable, we offer 2.5mm Extension cables that can be left attached to Blink's 2.5mm port for re-triggering the WiFi signal.
What can I connect to the circular jacks on my Blink?
Please connect only CamDo-approved accessories to these jacks. Do not connect other equipment, especially voltage sources such as your solar panel or battery, to these jacks. Doing so will damage your Blink or camera.
Does Blink work with your Battery Eliminators?
Blink is not compatible with our Battery Eliminators.
What does Blink weigh?
Blink weighs 19g. This compares to a GoPro camera at 87g plus the GoPro extended enclosure at 71g.
General support can be found on our Support pages here.
Also read the FAQ's tab for more information.
$50.00 USD
Get daily email notifications for the peace of mind that Blink and your GoPro camera are working as they should be.
A new feature implemented as of v2.00.00 Blink firmware is the ability to setup a scheduled email notification every day. In order to use this feature, Blink must be near a WiFi access point (either an open WiFi network or WPA secure network - WEP secure networks are older technology and not supported). This notification will send the following information:
We offer two payment options to suit your needs. Buy three months access to the Blink Email for flexibility (auto renewed unless cancelled). Or, pay one time and have unlimited access to Blink Email for life (best value). Blink Email is assigned to a single Blink and a subscription will need to be purchased for each Blink controller.
See the Blink User Manual for more information.
$135.00 USD
Product Code: MSM01
The marine grade aluminum swivel mount kit consists of a 6" long straight swing arm on a vertical mounting base for attachment to a flat or rounded surface such as a wall or post. The opposing end is a ball socket used with the 1.5" ball mount plate that can be attached to our Solar or DRY outdoor enclosure for ultimate aiming flexibility.
The swing arm pivot allows for full 360-degree rotation and the ball and socket system allows a 360-degree rotation with a 180-degree pivot.
There is an insert on the vertical mounting plate to allow solid mounting to a flat surface like a building or a rounded surface such as a pole or rail.
Included in the kit:
The mount is the perfect complement to our Solar and DRY outdoor enclosures and is included as an option with our Construction Time Lapse kits.
